Waterproof IP65 Solar Inverter Wifi Dongle Module

Smart WiFi-S

Equipment data monitoring
Multilevel Management
Remote update + configuration parameters
After-sales service
Direct connection configuration

Description

INTRODUCTION

WiFi Smart WiFi-S WiFi Module for Solar Inverter

The WiFi module can enable secure communication between off-network inverters and the monitoring platform. Simply, but this module connected to an inverter with communication cable and APP installed from Google Play or Apple stores, you can not only monitor the inverter parameters through your cell phone.

[ See instructions below for specific installation methods. ]

Enable access to historical data in centralized data center

Data transmission for data center

Access the inverter for remote monitoring and control via APP

General data
Product size (length/height/thickness) mm	122,568,527,2
Packing size (length/height/thickness) mm	1558035
NO	74,1g
GW	128,4g
Wi-Fi performance
Unreliable standards	802.11b/g/n
Frequency of work	2,400-2,483.5 MHz
Output power	802.11b: 18±2dBm
	802.11g: 16±2dBm
	802.11n: 15±2dBm
Receba Sensibilidade	CCK, 1Mbps: -96±2dBm
	CCK, 11Mbps: -85dBm
	6Mbps (1/2 BPSK): -88dBm
	54 Mbps (3/4 64-QAM): -70dBm
	HT20 (MCS7): -73±2dBm
	HT40 (MCS7): -70±2dBm
Electrical Parameters
Operational stress	12V
Maximum current	500mA
Work environment
Level of protection	IP65
Operating temperature	-40°C - +85°C
Storage temperature	-40°C - +125°C, <90% UR
Application parameters
Communication with Server	MQTT
Supported Network	2.4G
User configuration interface	APP or FSolar site
Dice upload cycle	10 minutes
Server domain name	https://shine.felicitysolar.com
